Bosch Serie | 4 Chimney extractor hood

600 Slimline Cookerhood Defy 600 Slimline Cookerhood
Bosch Serie | 4 Chimney hood

Call for Price

The optimum air volume for kitchen of all sizes.

No matter whether you have an open-plan kitchen and living-room or a small, closed-off kitchen. We offer the optimum air volume for kitchens of all sizes. Air should be exchanged 6 to 12 times an hour to ensure a consistently pleasant ambience. To do so, the air delivery volume or power of the cooker hood must be appropriate to the room volume.

TouchControl – control at your fingertips.

Set the exact power level with a single touch thanks to TouchControl and DirectSelect. It’s easy to operate: simply select the right power level or turn on the lights and away you go.

SKU: DWK97HM60 Category: Tag:

Description

Inclined hood: optimal for keeping an eye on your pots and pans.Inclined hood: optimal for keeping an eye on your pots and pans.

  • TouchSelect control: quick touch-control selection of desired settings and light.TouchSelect control: quick touch-control selection of desired settings and light.
  • Extraction rate: at 680 m3/h, it quickly ensures optimal kitchen air quality.
  • Especially silent: maximal extractor performance with minimal noise
  • Energy efficiency A: maximal extractor performance with minimal energy consumption
  • Energy Efficiency Class: A*
  • Noise max. Normal Level: 57 dB*
  • Suitable for ducted or recirculating operation
  • In recirculation operation chimless use possible
  • For recirculated extraction a recirculating kit or a CleanAir recurculation kit (accessory) is needed
  • Designed for wall mounted installation
  • touch control (3 speed + intensive operation) with Electronic display
  • Easy to clean
  • Twin channel high performance fan motor
  • 2 x 1,5W LED
  • Removable metal grease filters, dishwasher safe
  • Extraction rate according to DIN/EN 61591 ø 15 cm: max. Normal 420 m³/h Intensive 680 m³/h
  • Ducted extraction rate according to DIN/EN 61591max. 420 m³/h
  • Maximum extraction 420 m3/h
  • Extraction rate exhaust air according to EN 61591:
    max. normal use 420 m³/h, intensive 680 m³/h
  • Noise level according to EN 60704-3 and EN 60704-2-13 exhaust air:
    Max. normal use: 57 dB(A) re 1 pW (43 dB(A) re 20 µPa sound pressure)
    Intensive: 66 dB(A) re 1 pW (52 dB(A) re 20 µPa sound pressure)
  • Diameter pipe Ø 150 mm (Ø 120 mm enclosed)
  • Extraction rate in recirculation mode:
    Max. normal use: 390 m³/h
    Intensive: 560 m³/h
  • Noise levels in recirculation mode:
    Max. normal use: 66 dB(A) re 1 pW (52 dB(A) re 20 µPa sound pressure)
    Intensive: 75 dB(A) re 1 pW (61 dB(A) re 20 µPa sound pressure)
  • Power rating: 263 W
  • Dimensions exhaust air (HxWxD): 929-1199 x 890 x 499 mm
  • Dimensions recirculating with CleanAir module (HxWxD):
    1119 x 890 x 499 mm – mounting with outer chimney
    1189-1459 x 890 x 499 mm – mounting with telescopic chimney
  • Dimensions recirculating, chimney (HxWxD): 989-1259 x 890 x 499 mm
  • Dimensions recirculating, chimless (HxWxD): 453 mm x 890 x 499 mm
